Heat Exchanger  (Wet)

REF PART QTY PART REF PART QTY PART NO. NO. USED DESCRIPTION NO. NO. USED DESCRIPTION

1 130?6228 2 Plug, Anode

 2 Exchanger, Heat

 130?6267 1 MDDCA, MDDCB, MDDCC,

 MDDCF, MDDCG, MDDCK,

MDDCL, MDDCM and

MDDCN

130?6273 1 MDDCD, MDDCE, MDDCH,

 MDDCJ, MDDCP and

MDDCR

3 509?0399 2 Package, Heat Exchanger

 O’Ring

4 509?0400 2 Package, Heat Exchanger

 5 130?6266 1 Cap, Radiator

 6 Clamp, Hose

 503?2524 3 MDDCA, MDDCB, MDDCC,

 MDDCF, MDDCG, MDDCK,

MDDCL, MDDCM and

MDDCN

503?2532 3 MDDCD, MDDCE, MDDCH,

 MDDCJ, MDDCP and

MDDCR

7 130?6268 2 Cover, Heat Exchanger

 O’Ring

8 Clamp, Hose

 503?2523 1 MDDCA, MDDCB, MDDCC,

 MDDCF, MDDCG, MDDCK,

MDDCL, MDDCM and

MDDCN 9 130?6269 1 Tube, Seawater

 (Pump to Exchanger)

10 503?2525 1 Hose, Seawater

 11 Hose, Seawater

 503?2526 1 MDDCA, MDDCB, MDDCC,

 MDDCF, MDDCG, MDDCK,

MDDCL, MDDCM and

MDDCN

503?2522 1 MDDCD, MDDCE, MDDCH,

 MDDCJ, MDDCP and

MDDCR

12 800?6320 4 Screw, Flanged (M6 x 16mm)

 13 800?6321 4 Screw, Flanged (M10 x 35mm)

 14 323?2178 1 Plug, Exhaust Manifold

 15 Cock, Special Drain

 504?0269 1 MDDCA, MDDCB, MDDCC,

 MDDCF, MDDCG, MDDCK,

MDDCL, MDDCM and

MDDCN

504?0270 1 MDDCD, MDDCE, MDDCH,

 MDDCJ, MDDCP and

MDDCR

16 323?2179 1 Plug, Exhaust Manifold
